Xigmatek Vision Full Tower 3 Tempered Glass Panel Design BLACK
Availability: In stockSKU: 0018022
6901 EGP
- Type: Full Tower
- Color: Black
- Max GPU Length: 420 mm
- Max CPU Cooler Height: 180 mm
- Included Fans: 7 x 120mm PWM fans (3 reverse fans on the motherboard panel + 3 reverse fans on the PSU shroud + 1 rear fan)
- Warranty: 1 Year
External Features:
- Side Panels: 3 Tempered Glass Panels
In stock
Description
Xigmatek Vision Full Tower for High-Headroom Builds and Clean Cooling
The Xigmatek Vision Full Tower combines a spacious layout with extensive pre-installed airflow for a polished, high-performance build. Its tempered glass presentation and included PWM fans make it a strong fit for gaming systems and workstation setups alike.
Design & Compatibility
Built as a Full Tower with support for Full Tower form factor hardware, this chassis gives you the room to work with larger components and a more organized interior. It supports graphics cards up to 420mm long and CPU coolers up to 180mm tall, helping accommodate demanding builds without sacrificing clearance.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Xigmatek |
| Model | Xigmatek Vision Full Tower |
| Case Type | Full Tower |
| Form Factor Support | Full Tower |
| Max GPU Length | 420mm |
| Max Cooler Height | 180mm |
| Side Panel | 3 Tempered Glass Panel Design |
| Included Fans | 3 x 120mm PWM reverse fans on MB panel + 3 x 120mm PWM reverse fans on PSU shroud + 1 x 120mm PWM fan in rear |
| Color | BLACK |
| Warranty | 1 Year |
| Support Motherboard Up To | E-ATX |
| Support ATX Back Plug Motherboard | Supported |
| Fan Support | MB: 120mm x3 or 140mmx3; PSU Shroud: 120mm x3; Rear: 120mm or 140mm x1; SSD/HDD Mounting Bracket: 120mm x1 |
| Radiator Support | MB: 240/280/360 (EATX MB Width ≤ 290mm) |
| PSU Limitation | up to 220mm |
| Support GPU Vertical Installation | Supported |
| SSD HHD Mounting Bracket | Rear MB Panel, 3.5″ x1 or 2.5″ x2 |
| SSD HHD Mounting Flip Cover Option A | 3.5″ x3 or 3.5″ x2 & 2.5″ x1 or 3.5″ x1 & 2.5″ x2 or 2.5″ x3 (SSD/HDD Mounting Bracket without 3.5″ HDD or 12cm Fan) |
| SSD HHD Mounting Flip Cover Option B | 3.5″ x2 or 3.5″ x1 & 2.5″ x1 or 2.5″ x2 (SSD/HDD Mounting Bracket with 3.5″ HDD or 12cm Fan) |
| Bottom Mounted Magnetic Dust Filter | Included |
| Side IO Ports | Power Button, HD Audio Jack, USB 3.0 x2, Type C |
| Smart Fan Control LCD Display Panel | Included |
| Argb Pwm Hub | Included |
Additional Features
- Radiator Support: The front-to-back cooling layout supports 240mm, 280mm, or 360mm radiators, giving you flexible options for liquid cooling builds.
- Support ATX Back Plug Motherboard: Back-plug motherboard support helps keep front-side cable runs cleaner for a more streamlined interior.
- Smart Fan Control LCD Display Panel: The included control panel adds easy fan management and status visibility in one place.
Additional information
| case_type | Full Tower |
|---|---|
| max_gpu_length_mm | 420mm |
| Color | Black |
| warranty | 1 Year |
