Xigmatek Cubi M Nano Micro Tower Case

Description

Product Overview: Xigmatek Cubi M Nano Micro Tower Case

Dimensions:

• Length: 350mm
• Width: 280mm
• Height: 375mm

Motherboard Support:

• Micro ATX
• Mini ITX

Drive Bays:

• HDD Cage:
  • 3.5″ x1
  • 2.5″ x2

Fan Support:

• Top: 120mm x2 or 140mm x2
• MB Panel: 120mm x2
• Bottom: 120mm x2 or 140mm x2
• Rear: 120mm x1

Radiator Support:

• Top: 240mm
• MB Panel: 240mm
• Bottom: 240mm (without graphics card)

PSU Length Limitation:

• Up to 160mm

CPU Cooler Clearance:

• Up to 158mm

GPU Length Limitation:

• Up to 330mm

Expansion Slots:

• 4 standard slots

Power Supply:

• Standard PS2 ATX PSU

I/O Panel:

• USB 3.0 x1
• USB 2.0 x1
• HD Audio Jack
• Power Button
• Reset Button
• LED Switch

Material:

• Steel

Additional Features:

• Design:
  • 3 tempered glass panel design for aesthetic appeal
  • Superior airflow and ventilation design
• Pre-installed Fans:
  • Traditional fan blade on the rear side
  • Reverse fan blade on the MB panel and bottom side
• Dust Filters:
  • Top and bottom dust filters for easy maintenance
